Wilhelm Conrad Röntgen’s accidental discovery of X-rays on November 8, 1895, not only won him the first Nobel Prize in Physics in 1901 but also laid the groundwork for modern diagnostic medicine and radiology.

Discovery of X-rays+

Röntgen’s breakthrough happened while he was experimenting with cathode ray tubes at the University of Würzburg in Germany.

He noticed that a fluorescent screen across the room began to glow, even though it was too far from the tube to be affected by cathode rays.

This unexpected phenomenon prompted him to investigate further, leading to the identification of a new type of radiation, which he named X-rays—the “X” symbolizing an unknown quantity in mathematics.

These rays could pass through various materials, including paper, wood, and even soft tissue, though not through denser structures like bone or metal.

A cathode-ray tube (CRT) is a vacuum tube containing one or more electron guns, which emit electron beams that are manipulated to display images on a phosphorescent screen.

What Are X-Rays?

X-rays are a type of electromagnetic radiation, falling between ultraviolet (UV) light and gamma rays on the electromagnetic spectrum.

They have shorter wavelengths and higher frequencies than visible light, which gives them high energy.

This high energy allows X-rays to penetrate many materials, which is why they are widely used in medical imaging and material inspection.

Properties of X-Rays

Wavelength: Approximately 0.010.01 to 1010 nanometers.

Frequency: Between 3×10163×1016 Hz and 3×10193×1019 Hz.

Energy: Typically between 100100 eV and 100100 keV, which is strong enough to ionize atoms in the matter they penetrate.

Source: Wikipedia

X-rays are classified into soft X-rays (lower energy) and hard X-rays (higher energy). Soft X-rays are used for imaging soft tissues, while hard X-rays can penetrate denser materials like bone and metal.

Production of X-Rays

X-rays are produced when high-energy electrons strike a metal target, often tungsten. The process generally involves two types of X-ray production:

Bremsstrahlung Radiation (or braking radiation): Occurs when high-speed electrons are decelerated upon collision with the target metal’s atoms. The energy lost during this deceleration is emitted as X-rays. The X-ray energy depends on the speed of the electrons and the nature of the target metal.

Characteristic X-ray Production: Occurs when high-energy electrons knock out inner-shell electrons from target atoms. This creates vacancies, causing electrons from higher energy levels to drop into the lower energy states, releasing X-rays with energies characteristic of the element in the target.

X-Ray Tube

An X-ray tube is the device used to generate X-rays. It contains a cathode that emits electrons and an anode (often tungsten) as the target for the electrons. A high voltage accelerates the electrons from the cathode to the anode, where X-rays are produced as they strike the target.

Uses of X-Rays

Radiography: Produces images of bones and organs. Dense structures like bones absorb more X-rays, appearing white, while soft tissues appear darker.

CT Scans (Computed Tomography): A series of X-ray images taken from different angles are combined to create cross-sectional images of organs and tissues.

Mammography: Specialized X-ray imaging for detecting breast cancer.

X-rays are used in airport security to scan baggage and detect concealed items like weapons or drugs. The varying density of materials allows operators to identify objects based on how much X-ray each material absorbs.

Non-Destructive Testing: X-rays can identify structural flaws in machinery, buildings, and pipelines without damaging the object being tested.

X-ray fluorescence and diffraction help analyze the composition and structure of materials, including metals and crystals.

Scientific Principle

Photoelectric Effect: X-ray photons are absorbed by atoms, causing the ejection of inner-shell electrons. This effect is more pronounced in heavier elements, which absorb X-rays well.

Compton Scattering: X-ray photons collide with electrons and scatter, losing energy and changing direction. This effect is significant in imaging because scattered rays can reduce image clarity.

Pair Production: If the X-ray photon energy exceeds 1.02 MeV, it can create an electron-positron pair upon interaction with an atomic nucleus. This process is used in high-energy physics but not in routine X-ray applications.
